Quatro Stacker Wide Track — 4 (Four)-Post Lift 8,000 LB. (3.6T)
The Quatro Stacker is an ALI-certified four-post lift for use in both residential and commercial applications. This is the ideal storage, parking, and service solution for your vehicle lifting needs. It offers a lifting capacity of 8,000 lb. (3.6T) and clearance height for tall trucks, SUVs, and all varieties of cars.
Low Maintenance Problem-Free Design
70” / 1778mm stroke 3” / 76mm high pressure cylinder mounted under runway with prestressed 3/8” / 9.5mm lifting cables and 4” / 102mm steel pulleys.
Tough wheelabrator finished steel structure with premium double bake finish.
Built & Tested to Commercial Safety Standards
3rd party tested by M.E.T laboratories to meet or exceed the ANSI/ALI ALCTV 2017 Standard.
Single point automatic deadman safety with adjustable locking ladders with locks spaced every 6” / 152mm.
Premium Accessories Included with Each Lift
Each lift comes equipped with a removable caster wheel kit, three steel drip and drain pans, and one HD steel jacking tray.
A 3,500 lb / 1.5T hydraulic jacking beam and aluminum approach ramps are available as options.
Flexible Vehicle Loading
Low to the floor 4.3” / 109mm deck height with low angle removable approach ramps accommodates exotic sports cars and vehicles with low clearance ground effects.
Runways 18.7” / 475mm wide are adjustable from 74.8” /1902mm to 80-7/8” / 2054mm wide.
Premium North American Components
North American-made Monarch (Bucher) power unit, 3/8” / 9.5mm equalizing cables, cylinders, and hoses.
More Models to Choose From
Alternate model with 9,000 lb. / 4T capacity, lifting height of 82.3” / 2090mm, and 180-1/2” / 4585mm long runways.
Power units available in high efficiency 220v single phase 2HP / 1.5kw 8 amp or convenient 110v single phase 1HP / .75kw 15 amp.
Quatro Stacker XL Heavy Duty — 4 (Four) Post Lift 9,000 LB. (4T)
The Quatro Stacker Heavy Duty XL is an ALI-certified 4 (four) post lift for use in both residential and commercial applications. This is the ideal storage, parking, and service solution for your vehicle lifting needs. It offers a lifting capacity of 9,000 lb. (4T) and clearance height for tall trucks, SUVs, and all varieties of cars.
Low Maintenance Problem-Free Design
70” / 1778mm stroke 3” / 76mm high pressure cylinder mounted under runway with prestressed 3/8” / 9.5mm lifting cables and 4” / 102mm steel pulleys.
Tough wheelabrator finished steel structure with premium double bake finish.
Built & Tested to Commercial Safety Standards
3rd party tested by M.E.T laboratories to meet or exceed the ANSI/ALI ALCTV 2017 Standard.
Single point automatic deadman safety with adjustable locking ladders with locks spaced every 6” / 152mm.
Premium Accessories Included with Each Lift
Each lift comes equipped with a removable caster wheel kit, three steel drip and drain pans, and one HD steel jacking tray.
A 3,500 lb / 1.5T hydraulic jacking beam and aluminum approach ramps are available as options.
Flexible Vehicle Loading
Low to the floor 4.3” / 109mm deck height with low angle removable approach ramps accommodates exotic sports cars and vehicles with low clearance ground effects.
Runways 18.7” / 475mm wide are adjustable from 74.8” /1902mm to 80-7/8” / 2054mm wide.
Premium North American Components
North American-made Monarch (Bucher) power unit, 3/8” / 9.5mm equalizing cables, cylinders, and hoses.
More Models to Choose From
Alternate model with 8,000 lb. / 3.6T capacity, lifting height of 74.8” / 1900mm, and 165-3/8” / 4201mm long runways.
Power units available in high efficiency 220v single phase 2HP / 1.5kw 8 amp or convenient 110v single phase 1HP / .75kw 15 amp.
